Blue Sea Systems - 285 Series Circuit Breaker (40A)

Manufacturer: Blue Sea Systems
SKU: 632085071820
Manufacturer part number: 7184
$65.99
Blue Sea Systems - 285 Series Circuit Breaker (60A)

Product Description

  • Drop in replacement for 185-Series Circuit Breakers
  • Visible reset lever shows open condition
  • Ignition protected - Safe for installation aboard gasoline powered boats
  • Meets SAE J1171 external ignition protection requirements
  • Weather Resistant
  • Combines switching and circuit breaker function into one unit*
  • "Trip Free" - cannot be held closed after trip
  • Do not use as a switch where high inrush currents are expected.
Specifications
Amperage40A
Maximum Voltage48V DC
MountingSurface Mount
Circuit Breaker TypeThermally responsive Bi-metal blade
Terminal StudM6 (accepts 1/4" Ring Terminal)
Terminal Stud Torque50 in-lb (5.65 Nm)
Interrupt Capacity 3000A @ 48V
Minimum Operating Temperature-40° C
Maximum Operating Temperature85° C
Circuit Breaker ClassType III - switchable/manual reset - trip free
Weight0.50lb (0.23 kg)
